EN
LOFT

Function

Automatic range adjustment
After connection to a power
supply. Duration approx. 5 s.

Function description

Active range:

DIP switch 1
Serves to adjust the fi ttings active range to smaller washbasins.
‚ON' position = Standard active range (approx. 15 cm, default setting).
‚OFF' position = Short active range (approx. 12 cm, for smaller washbasins).
20 Washbasin fi tting
Water starts fl owing
As soon as the infrared sen-
sor detects the user within
the sensor range.
WimTec LOFT
Water stops fl owing
Once the user clears the
sensor range or after the
confi gured water arrest time
has elapsed.
ON
OFF
2 3 4 5 6
