SMART
Function
Automatic range adjustment
After connection to a power
supply. Duration approx. 5 s.
Function description
Active range:
DIP switch 1
Serves to adjust the fittings active range to smaller washbasins.
‚ON' position =
Standard active range (approx. 15 cm, default setting).
‚OFF' position =
Short active range (approx. 12 cm, for smaller washbasins).
22
Washbasin fitting
HyPlus
Water starts flowing
As soon as the infrared sen-
sor detects the user within
the sensor range.
WimTec SMART
HyPlus
Water stops flowing
Once the user clears the
sensor range or after the
configured water arrest time
has elapsed.
ON
OFF
1
2 3 4 5 6
