Operating manual
Digital display with analogue inputs
CODIX 530
Order code
1. Description
• 5-digit digital display with analogue inputs and
integrated totaliser.
• 8 mm high, very clear LED display for easy read-
ing.
• Display range from -19 999 to 99 999 with lead-
ing zero blanking
• Programming of the functions or operating pa-
rameters via the setting keys. Operating guid-
ance via the display while programming.
• Programmable features:
Measuring range
Independent decimal point adjustment for the mo-
mentary value display and the totaliser display
Displayed value for the lowest input signal
Displayed value for the highest input signal
Adding counter scale factor
Adding counter reset mode:
electrical
manual
manual and electrical
no reset
Digital mains hum suppression (50 or 60 Hz)
2. Inputs
MPI (Connect 4)
Multifunction input. Dependent to the setting of
the resetting function, this input operates as
LATCH or RESET input (see 4.10).
In LATCH mode, the current value displayed is
frozen, while measurement and adding continue
operating in the background.
In RESET mode, the adding counter is reset to 0.
The input (PNP) is activated with an input signal
of 4 ... 30 V DC. When falling below 2 V DC the
input is inactive.
CURRENT INPUT (Connect 5)
Analogue current measuring input with reverse
polarity protection and current limitation to 50 mA
maximum. Connect here the analog + signal wire.
Attention: This input is electrically isolated to
avoid interference from the supply voltage. Thus,
for the measurement, the most negative measure -
ment signal wire is to be connected with the ana-
log reference input.
6.530.012.300
ANLOGUE GND (Connect 6)
When electrical isolation between the measuring
loop and the supply voltage is not required, con-
nect 2 or 3 and this input (0V measurement sig-
nal) by means of a bridge.
VOLTAGE INPUT (Connect 7)
Analog voltage measuring input. Connect to pin 7
the analogue + signal wire. In case of a connec-
tion error, the message „Err4" is displayed.
Attention: This input is electrically isolated to
avoid interference from the supply voltage. Thus,
for the measurement, the most negative measure-
ment signal wire is to be connected with the ana-
log reference input.
3. Operating parameters adjustment
3.1 Switching between the display of the mo-
mentary value and of the adding counter
The right key allows switching between the dis -
play of the momentary measuring value and the
value of the adding counter.
Pressing this key once displays the active function
(„Act" or „Tot") for two seconds. If, during these
two seconds, the right key is pressed another
time, the active function is switched. This switch-
ing is confirmed by the display of „Act" or „Tot"
during approximately two seconds, and then the
device displays the value.
3.2 Setting the operating parameters
a. Hold down both keys on front panel and switch
on the supply voltage.
b. The display shows
c. After releasing the keys the display alternates
between menu title and corresponding menu
item at a frequency of 0.5 Hz. After any key is
pressed, only the menu item is displayed.
d. Pressing the right key, the menu item will be
switched to next value.
To input numerical values (e.g. when setting the
scaling factor), use the left key to select the
decade and the right one to set the value.
e. Hold down the left key and press the right key
