Module status LED:
Status
Off
Lights up green
Lights up red
Flashes red
Alternates between
red and green
Connection/Activity LED:
Status
Off
Lights up green
Flickers green
Lights up yellow
Flickers yellow
Connections and
Indicators on
M12 module
(6)
(7)
(8)
(9)
(10)
(11)
Network Status LED:
Status
Off
Lights up green
Meaning
No supply voltage
Normal operation
Major error (exception state, serious fault, etc.)
Minor error
Firmware update in progress
Meaning
No connection, no activity
Connection established (100 Mbit/s)
Activity (100 Mbit/s)
Connection established (10 Mbit/s)
Activity (10 Mbit/s)
(7)
(6)
2
3
5
1
4
(9)
(10)
Module status LED
Link/Activity LED 2
M12 connection 2
LED Network status
Link/Activity LED 1
M12 connection 1
Meaning
No IP address or exception state
At least one Modbus message received
Englisch (US)
(1) TXD+
(8)
(2) RXD+
(3) TXD-
(4) RXD-
(5) Shield
(11)
