Dear client,
Congratulations on your purchase of this product. Like all FLOTEC products, it has been developed with the help of
the latest technologies and manufactured with the most advanced electrical/electronic parts. Take the time to read
the instructions carefully before using this appliance. Thank you!
Contents
Ch. 1 - Features -------------------------------------------------------------
Ch. 2 - Transportation and storage ------------------------------------------
Ch. 3 - Limitations -----------------------------------------------------------
Ch. 4 - Motor assembly ------------------------------------------------------
Ch. 5 - Electric pump installation --------------------------------------------
Ch. 6 - Electric connection ---------------------------------------------------
Ch. 7 - Starting the unit ------------------------------------------------------
Ch. 8 - Maintenance and troubleshooting ------------------------------------
Warnings for the safety of individuals and things. Please pay careful attention to the following signs
and indications.
DANGER
Electric shock
risk
DANGER
Risk of bursting
DANGER
WARNING
DANGER
WARNING: Before installing this pump read this manual carefully. Any damage caused by failure to observe any
directions in this manual will not be covered by warranty.
CH. 1 - FEATURES
SCM 4 Plus® pumps can be supplied with or without electric motor. This booklet supplies all the information con-
cerning the use and maintenance of these machines.
SCM 4 Plus® pumps are submersed. The multi-stage pumping unit is directly coupled to the submersed electric motor.
CH. 2 - TRANSPORT AND STORAGE
Each machine is carefully tested and packed during the assembly phase. On receiving the pump, customers will
have to verify: that the product complies with the data quoted in the order; that is has not suffered damages during
transportation. All damages should be immediately reported to the distributor within 8 (eight) days from the date of
purchase. Don't disperse and/or throw the packaging away and take all possible measures to re-use it and recycle
it. Before transporting the unit, check the following data:
- weight of the pump (or the pump end)
- overall dimensions
- lifting points
The pump (or the pump end) has to be transported with equipment suitable to its weight and dimensions. Only pumps
6

GENERAL SAFETY WARNING

Warns that the failure to follow directions may cause electric shock.
It indicates that the failure to comply with the instruction given can cause
an explosion.
Warns that failure to follow directions could cause serious risk to persons
or things.
It indicates that the failure to comply with the instruction given can damage
the pump.
This appliance can be used by children aged 8 years or over and by persons with limited
physical, sensory or intellectual capabilities, or with limited experience and knowledge,
provided that they are supervised or have been instructed in the safe use of the appliance
and are aware of the dangers involved. Children must not be allowed to play with the
appliance. Cleaning and user maintenance must not be carried out by children unless
they are supervised
