Before you drive, check the correct function of the vehicle: does it react accurately on your remote control? If not, e.g.
the steering servo trembles or uncontrolled throttle reaction, start driving in no case. Check whether the transmitter
batteries have enough voltage or the car battery is fully charged and change it and/or recharge if necessary. Also you
should control the directional stability, a central position of the steering wheel at the transmitter means the model runs
straightforward. You can correct this by the trim lever above the steering wheel. Press the lever into the desired direction
until the car runs in a straight line.
The run time depends on the surface. In high grass the run time is naturally shorter than on the fl at road. When the bat-
tery dumps, fi rst the car runs slower, then the speed controller completely switches off and the vehicle stops. The ESC
has a built-in LiPo safe circuit, when the LiPo reaches 2.65 V per cell the motor will stop.
After driving take the battery out of the vehicle, otherwise uncontrolled starting of the motor may damage the speed
controller or the batteries.
Don't drive against obstacles, which the model cannot overcome, and stay on full throttle. This can destroy the engine,
electronic speed controller or the transmission!
Don't drive in wet grass or puddles, because the electronic equipment (servo, receiver and speed controller) is not wa-
terproof. If you want to drive in the wet, these parts must be protected waterproof (e.g. by a ballon).
Specifi cations ESC:
Number of cells NiMH
Number of cells LiPo
Constant current forward
BEC
Undervoltage protection
PWM frequency
Dimensions
Weight
Receiver connector
SERVICE
In addition to the already described service work should always try to keep your vehicle in order to prevent wear. If there
is dirt in moving parts, this can affect the performance of the model signifi cantly. Remove dirt or dust with compressed
air, a soft brush and / or with a toothbrush. If possible, try using no solvents, as this can move the dirt in normally inac-
cessible places and thus cause additional wear. We recommend the following simple procedures:
• Remove dirt and dust as far as possible with the methods described above.
• Check the car for worn, broken or gripping parts and repair them if necessary.
• Check regularly the fi xed seating all screws and tighten them if necessary.
SERVICE AND REPAIR, SPARE PARTS
For the Roadfi ghter ST all parts are available as spare parts. So if a part is defective or worn, you can identify these
parts with the Exploded view, buy these parts and fi x the car yourself with the help of the assembly instruction (pages
29 - 41).
In problem cases, or for questions and repairs, please contact the Service department in your country (see
warranty card on page 43) or:
GRAUPNER-Service, Henriettenstrasse 94-96, D-73230 Kirchheim/Teck,
Tel. +49/1805/472876
SPARE PARTS: at your local hobby shop or online at Graupner spare-parts Shop http://www.graupner-ersatzteilshop.
de/ under order.-nr.: 90166.RTR
GM-Racing 90166.RTR Roadfi ghter ST Stadium Truck
6 - 7 (7.2 - 7.4 V)
2 (7.4 V)
80 A (150 A ~ 1 sec.)
5.75V/3A
LiPo 2-cell < 5.3 V
2 KHz
ca. 42x37x30 mm (w/o wiring)
approx. 24g
Graupner/JR
