9.6 Making inside cuts
This scroll saw allows inside cuts in workpieces with-
out damaging the outside or the circumference of the
workpiece.
1. Remove the saw blade (22) as described in 9.1.3.
2. Drill a hole into the workpiece.
3. Place the workpiece with the drilled hole over the
opening of the table inlay (26) on the saw table (6).
4. Install the saw blade (22) through the drilled hole in
the workpiece and set the blade tension.
5. After completing the inside cut, remove the saw
blade (22) from the blade holders (as described in
9.1.3).
6. Remove the workpiece from the table.
9.7 Mitre cutting (fig. 14)
WARNING
Be especially careful when making mitre cuts. The an-
gle of the saw table makes it easier for the workpiece
to slip. There is a danger of injury.
1. To carry out mitre cuts adjust the distance of the
blade guard for worktable accordingly.
2. Swivel the saw table by loosening the locking lever
(14) and tilting the table (6) to the desired position.
3. Tighten the locking lever (14).
10. Electrical connection
The electrical motor installed is connected and
ready for operation. The connection complies with
the applicable VDE and DIN provisions.
The customer's mains connection as well as the
extension cable used must also comply with these
regulations.
Damaged electrical connection cable
The insulation on electrical connection cables is often
damaged.
This may have the following causes:
• Passage points, where connection cables are
passed through windows or doors.
• Kinks where the connection cable has been improp-
erly fastened or routed.
• Places where the connection cables have been cut
due to being driven over.
• Insulation damage due to being ripped out of the wall
outlet.
• Cracks due to the insulation ageing.
34 | GB
Such damaged electrical connection cables must not
be used and are life-threatening due to the insulation
damage.
Check the electrical connection cables for damage
regularly. Make sure that the connection cable does
not hang on the power network during the inspection.
Electrical connection cables must comply with the ap-
plicable VDE and DIN provisions.
Only use connection cables with the marking H 05 VV-F.
The printing of the type designation on the connection
cable is mandatory.
AC motor
The mains voltage must be 220-240 V~.
Extension cables up to 25 m long must have a
cross-section of 1.5 mm
Connections and repairs of electrical equipment may
only be carried out by an electrician.
Connection type Y
If it is necessary to replace the mains connection ca-
ble, this must be done by the manufacturer or their
representative to avoid safety hazards.
Please provide the following information in the event
of any enquiries:
• Type of current for the motor
• Machine data - type plate
11. Transport
• Transport the electric tool by lifting it on the recesses
provided for this on the frame and the engine cover.
• Never use the protective devices for handling or
transport.
• Make sure that the exposed part of the saw blade
is covered during transport, e. g. by the protective
device.
12. Cleaning, maintenance, storage
and ordering of spare parts
WARNING
Always switch the machine off and remove the mains
plug prior to all maintenance and cleaning work.
12.1 Cleaning
Keep all safety devices, air vents and the motor hous-
ing free of dirt and dust as far as possible. We recom-
mend that you clean the equipment immediately after
you use it.
