metals (iron nail, 5¢ nickel coin, pull-tab, 1¢ Zinc coin, 10¢ copper
coin and 25 ¢ silver coin) 7-10cm (2.5"-4") above the search coil
respectively.
a. The detector sounds three different tones in turn.
b. The depth cursor indicates the second grade.
c. The target cursor flashes respectively. The digital cursor shows the
corresponding number. As shown in the following table:
Sample
Tone
Identification
cursor
indication
Digital cursor
indication
(See Fig.10 with an iron nail as an example)
5¢
Iron
nickel
nail
coin
Low
Low
tone
tone
10-40
41-50
1¢
Pull-tab
zinc
coin
Middle
Middle
tone
tone
55-70
72-75
11
10¢
25¢
copper
silver
coin
coin
High
High
tone
tone
80-83
86-88
Fig.10
