DECOR ATI VE COVE R AS SE MB LY
*Only for the model WITHOUT LIGHT
• Once the connection plate is assembled and secured, screw the decorative cover back to
the connection plate using the central screw.
LIGH T AS SE MB LY
*Only for the model WITHOUT LIGHT
• Connect the single pin sockets on the breakout board to those on the LED panel. The LED
panel is magnetized so it attaches to the connection board by simply putting both pieces
together.
Note: While installing or removing the LED board, be careful not to touch the insulating tabs.
Do not overtighten the screws or thread them too quickly as this could cause damage to the
insulating tabs.
• Finally, place the decorative light shade by screwing it onto the LED plate.
C H EC K I N STAL L AT IO N
• Check the correct operation of the ceiling fan, checking that no strange movement or mis-
alignment is observed in any part of the fan.
• If you notice any type of hum/vibration, you can proceed to adjust the blades with the bal-
ancing kit.
• This kit has self-adhesive counterweights and "u" shaped clips.
• Turn off the ceiling fan.
• You can put the clip in the center of any blade and check to see if the vibration decreases.
• Turn on the fan and check. If no change is seen, turn off the fan and add another clip on
another blade or use the adhesive weights.
