The maximum ambient temperature T
= 45° C must never be exceeded.
a
Operate the device only after having become familiarized with its functions. Do not permit operation by
persons not qualified for operating the device. Most damages are the result of unprofessional operation!
Never use solvents or aggressive detergents in order to clean the device! Rather use a soft and damp cloth.
Please use the original packaging if the device is to be transported.
Please consider that unauthorized modifications on the device are forbidden due to safety reasons!
Never remove the serial barcode from the device as this would make the guarantee void.
If this device will be operated in any way different to the one described in this manual, the product may suffer
damages and the guarantee becomes void. Furthermore, any other operation may lead to dangers like short-
circuit, burns, electric shock, crash etc.
DESCRIPTION OF THE DEVICE
Features
Powerful professional COB spot
• Equipped with 7 x 30 W TCLs (tricolor LEDs)
• Supports RDM (Remote Device Management)
• Functions: static colors, RGB color blend, automatic color change, internal programs, dimmer and strobe
settings via DMX, Master/Slave
• Dimmer speed (step response) adjustable
• Sound-control via built-in microphone; adjustable sensitivity via Control Board
• 3, 4, 5, 6, 21, 22 or 25 DMX channels selectable
• Each LED can be controlled individually
• DMX-controlled operation or stand-alone operation with Master/Slave function
• With color-filter frame and removable Fresnel lens module
• Optional barndoors available
• Rugged housing and an appealing design
• Comfortable addressing and setting via Control Board with LC display and four operating buttons
• Ideal as floor spot via additional bracket
• Locking possibility at the brackets
• Switch-mode power supply for operation between 100 and 240 Volts
• Power connection via Neutrik PowerCon jack and included power cable
• DMX control via every standard DMX controller
• Available in silver or in black
25/40
00080219.DOC, Version 1.0
