commeo initial operation/Setting
4. commeo initial operation/Setting
commeo initial operation
The commeo initial operation is only possible using commeo transmitters. To com-
plete the settings in the receiver, the receiver must be selected with a transmitter in
SELECT mode. In SELECT mode, there is only one connection at a time to a receiver.
Only this one can be moved and set.
4.1. Selection of a receiver
By pressing the SELECT button for 3 seconds the transmitter will be put into the
SELECT mode. After the SELECT mode has been started, the status LED will start to
flash quickly and the transmitter will look for the receiver. The status LED being lit in
green indicates that the receiver has been found and the status LED will flash slowly
in orange. The first receiver completes a brief confirmation run. If no receivers have
been found this will be indicated by the status LED being lit in red.
Receiver selection with non-programmed transmitter/initial operation
>1 s
or
Receiver selection with programmed transmitter
1. Select the transmitter channel on which the receiver is programmed.
2. Push the SELECT button at the transmitter for 3 seconds. The transmit-
ter is in SELECT mode.
3 s
Note: The receivers found by this method can now be found using another non-pro-
grammed transmitter within 4 minutes. Press the SELECT button on the additional
transmitter for 3 seconds for this purpose. The transmitter is in SELECT mode. All set-
tings can now be completed with both transmitters.
1. Interrupt the voltage supply of the receivers for
>1 second. The receivers can be found within the
next 4 minutes.
2. Push the SELECT button at the trans mitter for 3 sec-
3 s
onds. The transmitter is in SELECT mode.
