Assembly and adjustments
3.3
Adjustment of roller unit (kerbstone)
The working height (0-25 cm) of the device (TAS-UNI) can
be adjusted with the spindle (1).
Place the roller unit on the kerbstone.
Release the eyebolt (2).
Adjust the screeding profile on the crank (1) in that way,
that the screeding profile rests on the facing bedding
sand. Orientaion on the scale (3).
➔TIPP Optimal facing bedding sand (grit height) 2-3
cm.
Fasten eyebolt (2) again.
51000100 / 51000101
Roller unit
Kerbstone
Facing bedding sand
14 / 19
(1)
(2)
(3)
Fig. 2
GB
