Fig. 5
(1) Left/right navigation
arrow
Left/right navigation arrow Fig. 5 (1):
- Navigate in the menu. After the last menu page, the first
page appears again.
Confirm Fig. 5 (2):
- Activating/deactivating a function.
Open a submenu.
-
Confirm a selection. After confirmation the display
-
switches back to the menu.
Back to Status display: in the fastest manner:
Close and open the door.
-
- or wait 10 seconds. The display switches to the Status
display.

6.1.3 Controls

The controls are explained by a template. The display
changes depending on the function or settings.
Fig. 6
(1) Status deactivated /
status activated with
white bar in the lower
area
(2) Symbol or activated
value

6.1.4 Display symbols

Display symbols provide information about the status of the
appliance.
Symbol Appliance status
Standby
The appliance or temperature zone
is switched off.
Flashing number
Appliance is working. Temperature
flashes until the set value is
reached.
Flashing symbol
Appliance is working. Setting has
been made.
White bar in the upper area builds
up when a function is activated.
The bar disappears when the func‐
tion is active.
* Depending on model and options
(2) Confirm
(3) Status bar builds up
as the function is acti‐
vated.
Symbol Appliance status
White bar in the lower area
Function is activated.
Back
confirmed, the menu jumps to the
next higher level.

6.2 Control concept

6.2.1 Activating/deactivating the function

You can activate/deactivate the following functions:
Symbol Function
Quick Cool
Vacation function
x When function is on, the appliance works harder. This
means appliance noise when operating may be louder for
a short while, and more energy will be consumed.
u Press the navigation arrows Fig. 5 (1) repeatedly until the
function is displayed.
u Press Confirm Fig. 5 (2).
w You hear the confirmation tone.
w Status appears in the menu.
w Function is on/off.

6.2.2 Selecting function value

With the following functions you can set a value in the
submenu:
Symbol Function
Setting the temperature
Switch the appliance on/off
u Tap the navigation arrows Fig. 5 (1) repeatedly until the
function is displayed.
u Press Confirm Fig. 5 (2).
u Select the setting value with the navigation arrows
Fig. 5 (1).
Setting the temperature
u Press Confirm Fig. 5 (2).
w You hear the confirmation tone.
w Status: On Fig. 6 (1) appears briefly in the submenu ().
w Display switches back to the menu.

6.2.3 Activating/deactivating settings

You can activate/deactivate the following settings:
Symbol Setting
Sabbath mode
CareMode
Reset 2
Switch off
Controls
When the display is
x
2
2
2
