Balance Charger xMove 2.0/xBase 2.0
Instruction Manual
Microprocessor controlled high-performance rapid charger/
discharger for Nicd/NiMH/Lithium/Pb batteries with an
integrated cell voltage balancer.
USB PC link, temperature sensor and integrated lithium
battery balancer.
Charge current up to 5 A, discharge current up to 1 A,1 to 6
series of Lilo/LiPo/LiFe, 1 to 15 cells of NiMH, 2 to 20 V of
Lead-acid (Pb).
Content
1. Special Features ................................................2
2. Exterior of the Unit ............................................3
3. Warnings and Safety Notes ..................................4
4. Program Flow Chart ...........................................6
5. Initial Parameter Set Up (Users set up) ...................7
6. Lithium Battery (Lilo/LiPo/LiFe) Program ...............9
7. Charging Lithium Batteries ...................................9
8. Charging Lithium Battery at Balance Mode ...............9
9. Individual Cell Connection Diagram
(Pin-Assignment of 8-Pin) .................................. 10
10. 'FAST' Charge Lithium Battery ............................ 11
11. 'STORAGE' Control Lithium Battery ...................... 11
12. Discharging Lithium Battery ............................... 12
13. NiMH/NiCd Battery Program ............................. 12
14. Charging NiCd/NiMH Battery ............................. 13
15. Discharging NiCd/NiMH Batteries ....................... 13
16. Charge-to-Discharge & Discharge-to-Charge Cycle
NiMH/NiCd Battery ......................................... 14
17. Pb (lead-sulphuric acid) Battery Program ............... 14
18. Charging Pb Battery ......................................... 15
19. Discharging Pb Battery ..................................... 15
20. Save Data Program ......................................... 16
21. Load Data Program ......................................... 17
22. Various Information During the Process ................. 18
23. Warning and Error Messages .............................. 19
24. Glossary of Terms ............................................ 20
25. Specifications ................................................. 20
26. Maximum Circuit Power Chart ............................ 21
Please read this entire operating manual completely and attentively
as it contains a wide variety of specific programming and safety
information. You need to keep this manual in a safe place, and be
sure to pass it on to the new owner if you ever dispose of xMove 2.0/
xBase 2.0.
We reserve the right to commit modifications. Copyright reserved.
2

1. Special Features

Optimised operating software
When charging or discharging, xMove 2.0/xBase 2.0 has an "AUTO"
function that sets the feeding current automatically for Lithium
batteries. It can prevent the over-charging, which can lead to an
explosion by users fault. Every program in the unit is controlled
with mutual links and communication for every possible error, so it
introduces a maximum safety. These can be set at users option.
Individual voltage balancer for Lithium
batteries inside
xMove 2.0/xBase 2.0 has an individual-cell-voltage balancer inside,
so it does not need any balancer separately when charging Lithium
batteries (Lilo/liPo/LiFe) for cell voltage balancing.
Balance individual cells on discharge
xMove 2.0/xBase 2.0 also can monitor and balance individual cells
of lithium battery pack during the discharge process. If the voltage of
any one cell varies abnormally, the process will be stopped with the
error message.
Accept various trpes of Lithium
batteries
xMove 2.0/xBase 2.0 can accept three types of Lithium batteries:
Lilo, LiPo and LiFe. They have different characteristics by their
chemistry. You can select any one of them that you are going to
process before the job. For their specifications, refer "Warnings and
safety notes" section.
Lithium battery 'Fast' and 'Storage'
mode
You can charge Lithium battery for special purposes. 'Fast' charge
reduces charging time of Lithium battery and 'Storage' mode controls
the final voltage of the battery to be suit for long time storage.
Maximum safety
Delta-peak sensitivity: The automatic charge termination program
works on the principle of the Delta-peak voltage detection (NiCd/
NiMH).
Auto-charge current limit: When charging NiCd or NiMH at 'AUTO'
current mode, you can set the upper limit of charge current to avoid
from high current charging. This is very useful when charging the low
impedance and small capacity NiMH battery in 'AUTO' mode.
Capacity limit: The charging capacity always calculated by multiple
of the charging current and time. If the charging capacity exceeds the
limit, the process will be terminated automatically when you set the
maximum value.
Temperature limit: The temperature of the battery on charging
will rise by its internal chemical reaction. If you set the limit of
temperature the process will be expired forcibly when the limit has
reached.
Processing time limit: You can also restrain the maximum process
time to prevent form any possible defect.
