12. Discharging Lithium Battery

*Voltage balancing and monitoring during the discharge
The processor monitors the voltage of individual cells during
'storage-mode' and 'discharge' of Lithium battery pack. It tries to
normalize the voltages to be equal. For this feature, the individual
plug of the battery pack should be connected to the individual port
of the charger.

13. NiMH/NiCd Battery Program

These programs are for charging or discharging NiMH (Nick-Metal-
Hydrid) or NiCd (Nickel-Cadmium) battery, commonly used for R/C
model applications.
12
The value of discharge current on the left side of screen may not
exceed 1C for a maximum safety and the final voltage on the right
should not be under the voltage level that is recommended by the
battery manufacturer to avoid deep discharging.
To start to discharge press "Start/Enter" key for more than 3 seconds.
This shows the present state of discharge. To stop discharging press
"Batt type/Stop" key once.
If the voltage of any one or more cells varies abnormally during
the procedure, xMove 2.0/xBase 2.0 terminates the process
forcibly with the error message. If this happens, the battery pack
contains a bad cell, or the bad connection of the cable or plug. You
can easily know which one cell is bad by pressing INC ► button at
time of showing the error message.
The processor found that the voltage of one of the cells in the
Lithium battery pack is too low.
In this case, the 4th cell is bad. If there happens the connection-
break of the cable or plug, the voltage value may show zero.
To alter the value at the display, press "Start/Enter key" to make it
blink then change the value using INC ► or ◄ DEC key. The value
will be stored by pressing "Start/Enter" button for more than 3
seconds.
