8.1 Replacing the fuse
If the fine-wire fuse of the device fuses, only replace the fuse by a fuse of same type and rating.
Before replacing the fuse, unplug mains lead.
Procedure:
Step 1: Open the fuseholder on the rear panel with a fitting screwdriver.
Step 2: Remove the old fuse from the fuseholder.
Step 3: Install the new fuse in the fuseholder.
Step 4: Replace the fuseholder in the housing.
Should you need any spare parts, please use genuine parts.
If the power supply cable of this device becomes damaged, it has to be replaced by a special power supply
cable available at your dealer.
Should you have further questions, please contact your dealer.
9. TECHNICAL SPECIFICATIONS
Power supply:
Power consumption:
DMX512 connection:
Number of DMX channels:
Number of LEDs:
Type of LEDs:
TV spigot:
Beam angle:
Sound control:
Maximum ambient temperature T
Maximum housing temperature T
Min. distance from flammable surfaces:
Min. distance to lighted object:
Dimensions (LxWxH):
Weight:
9.1 Accessories
EUROLITE FP-1 Foot pedal
EUROLITE STV-40A Lighting stand, alu
EUROLITE STV-40-WOT Lighting st.no T-bar
EUROLITE STV-40S-WOT Lighting st.no T-bar
EUROLITE DMX LED Operator 4
EUROLITE DMX LED Operator IR2DMX + IR RC Item no. 70064512
Please note: Every information is subject to change without prior notice. 14.09.2011 ©
230 V AC, 50 Hz ~
100 W
3-pin XLR
15
720 (240 x red, 240 x green, 240 x blue)
10 mm
D = 28 mm
25°
via built-in microphone
:
45° C
a
(steady state): 60° C
B
0.50 m
0.10 m
1200 x 55 x 310 mm
8.5 kg
Item no. 42109710
Item no. 59007001
Item no. 59007002
Item no. 59007004
Item no. 70064504
31/32
00056674.DOC, Version 1.2
