Chapter 1. Foreword
1.1. Preface
This manual has been drawn up in compliance with the UNI10893 standard dated July 2000. It is meant for all users in
order to enable them to use the machine correctly. Keep it in a place which can be easily accessed in the proximity of the
machine and which is known to all users. This manual is an integral part of the machine for safety reasons. We wish to
specify the symbols in use here below in order to improve their understanding.
ATTENTION:
Accident prevention rules for the operator. This warning indicates the presence of dangers which
can injure the person operating on the machine.
ATTENTION:
Hot members. It shows the danger of burning, thus involving the risk of a serious accident for the
exposed person.
WARNING:
It indicates the possibility of damaging the machine and/or its components.
All reproduction rights of this manual are reserved to the manufacturer. Partial or complete reproduction is forbidden as
provided by the law. Descriptions and pictures provided on this manual are not binding. Therefore the manufacturer,
reserves the right of making any change considered necessary. This manual cannot be transferred for viewing to third
parties without authorisation in writing of the manufacturing company. The machine must be used only for the purpose it
was built. Any other use shall be considered as "illegitimate use" and therefore dangerous. Before carrying out any
operation on the machine it is compulsory to read carefully all instructions provided on this manual, in order to avoid
possible damage to the machine, to people and property.
Do not operate in case of doubts on the correct interpretation of the instructions.
Contact the manufacturer in order to obtain the necessary explanation.
Upon delivery check that the machine is complete in all parts.
Possible anomalies shall be immediately reported to the manufacturer.
The manufacturing company disclaims any responsibility in case of machine illegitimate use and/or in case of damages
resulting form operations carried out on the machine that are not mentioned in this manual.
1.2. Performances of packaging machine
You have bought a machine with outstanding features and performance and we thank you very much for your confidence
in choosing it. The system is unique in its kind and has achieved worldwide success with more than 70000 units
operating in the field of packaging and wrapping.
The technological concept underlining its design, as well as the components and materials used in the manufacturing
and testing process are the best assurance of proper operation and long-lasting liability.
Thanks to its particular operating circuit, it can be used both as a sealing and shrinking machine or as a plain sealing
machine (sealing only). In this case it is possible to pack the object in a soft bag without shrink-wrapping. The film used
in centerfolded execution can be micropunched or not when running through the micropunches of machine itself.
1.3. Machine identification
In every communication with the Manufacturer, always mention the model and the serial number specified on the plate
on the rear part of the machine (figure 1.3. page 58).
1.4. Technical data of the machine
Package weight and sizes
FM75
a = mm1050
FM76
a = mm1350
Machine weight and sizes
FM75
a = mm1190
FM76
a = mm1390
Electrical system
Voltage (V): see data on plate
Frequency (Hz): see data on plate
Maximum absorbed power (W): see data on plate
Maximum absorbed current (A): see data on plate
Maximum production
300 packages/hour.
b = mm825
c = mm770
b = mm960
c = mm820
b = mm650
c = mm1300
b = mm750
c = mm1400
Weight = Kg115 (figure 1.4.A page 58).
Weight = Kg153 (figure 1.4.A page 58).
Weight = Kg93 (figure 1.4.B page 58).
Weight = Kg122 (figure 1.4.B page 58).
