hanseatic HGS14355CNFI Gebrauchsanleitung Seite 57

(28)
(23)
5. Turn the lower hinge (23) over and screw
the hinge pin (28) and snap ring (29) back
on.
(4)
6. Unscrew the left screw foot (4).
Fitting the lower hinge and
appliance door
(23)
(22)
(4)
1. Screw on the lower hinge (23) on
the left with the two screws (22) and
screw the screw foot (4) back in.
Use the screwdriver to tighten the
screws by just 2 to 3 turns, and then use
the 8 mm spanner to tighten them fully.
2. Place the appliance upright.
3. Re-insert the appliance door (2).
(29)
Assemble the upper hinge
(27)
(17)
1. Tighten the upper hinge (18) with the
screws (20).
2. Re-place the hinge cover (17).
3. Re-place the cover (19) on the opposite
side.
4. Insert the blind plug (21).
First use Page EN-25
(20)
(18)
(19)
(21)
