Page EN-24 First use
(22)
6. Loosen the screws (22) on the low-
er hinge (23), unscrew the right screw
foot (4) and remove the lower hinge.
7. Screw the right screw foot (4) back in.
(24)
8. Loosen the screw (24) and re-insert it on
the opposite side.
Prepare the appliance door and
lower hinge
(23)
(4)
1. Reposition the door handle (3) if neces-
(4)
2. Loosen the screw on the plastic insert (25)
3. Screw the plastic insert (26) on the oppo-
4. Using the 10 mm spanner and pliers,
(3)
sary. Read the section "Attaching the door
handle" again at page EN-22.
(25)
of the appliance door and remove the
plastic insert.
site side of the appliance door (2).
(28)
(23)
loosen the nut (27) for the hinge pin (28)
on the lower hinge (23) and remove it to-
gether with the snap ring (29).
(26)
(29)
(27)
