GRAPHITE 58GE113 Benutzerhandbuch Seite 9

• Turn off the display by pressing and holding the button for
approximately 3 seconds until the LCD turns off.
• Remove the battery from the tool or disconnect the power plug from
the cigarette lighter.
PUMPING WITH A HIGH-PRESSURE HOSE
NOTE: Use caution and stand half a metre away.
NOTE: Standard adapters vary from country to country.
NOTE: The air holder on the high-pressure hose can be used without
an adaptor to inflate motor vehicle tyres or with any nozzle that has
a pin that fits into the end hole of the high-pressure hose.
• Insert the battery into the compressor or the cigarette lighter plug of
the 12VDC cigarette lighter power source.
• Release the high-pressure hose end lock Fig. E1.
• Clamp the end of the high-pressure hose fig. B2 onto the valve and
lock the end until it is parallel to the hose fig. E2.
• Set the target pressure on the LCD display using the '
buttons then set the main switch to the 'I' position to start pumping.
• The tool will continue to operate until the target pressure is slightly
exceeded, and then reduce pressure to reach the target pressure.
• When the desired pressure is reached and the tool has stopped, set
the main switch to "O".
• Turn off the display by pressing and holding the Fig. D4 LCD button
for a few seconds until the display switches off.
• Remove the battery from the tool or disconnect the power plug from
the cigarette lighter.
There are 3 working tips for the high-pressure hose set:
• Needle for sports balls
• Tapered adapter
• Presta valve adapter
Adaptor holder
The needle and adapters can be stored by inserting them directly into the
tip shank, as shown in Figure B.
INSTALLATION OF WORKING TIPS
NEEDLE FOR SPORTS BALLS
• Release the high-pressure hose end lock Fig. E1
• Fit the needle tip fig. E4 and lock it onto the end of the high-pressure
hose
• Set the target pressure on the LCD display using the '+' and '-'
buttons then set the main switch to the 'I' position to start pumping.
• The tool will continue to operate until the target pressure is slightly
exceeded, and then reduce pressure to reach the target pressure.
• When the desired pressure is reached and the tool has stopped, set
the main switch to "O".
CONICAL TIP
You can inflate small items such as beach balls, swimming sleeves or
inflatable swimming tubes.
• Release the high-pressure hose end lock Fig. E1
• Fit the needle tip fig. E3 and lock it onto the end of the high-pressure
hose
• Set the target pressure on the LCD display using the '+' and '-'
buttons then set the main switch to the 'I' position to start pumping.
• The tool will continue to operate until the target pressure is slightly
exceeded, and then reduce pressure to reach the target pressure.
• When the desired pressure is reached and the tool has stopped, set
the main switch to "O".
PRESTA ADAPTER
Presta adapter allows you to inflate bicycle wheels using a car pump
• Release the high-pressure hose end lock Fig. E1
• Fit the nozzle with the PRESTA adapter fig. E5 and lock it onto the
end of the high-pressure hose.
• Set the target pressure on the LCD display using the '+' and '-'
buttons then set the main switch to the 'I' position to start pumping.
• The tool will continue to operate until the target pressure is slightly
exceeded, and then reduce pressure to reach the target pressure.
• When the desired pressure is reached and the tool has stopped, set
the main switch to "O".
After pumping with adapters or a needle:
• Turn off the display by pressing and holding the Fig. D4 LCD button
for a few seconds until the display switches off.
• Remove the battery from the tool or disconnect the power plug from
the cigarette lighter.
MAINTENANCE AND STORAGE
NOTE: Always ensure that the tool is switched off, the battery has been
removed from the socket, or the power plug has been removed from the
cigarette lighter socket, before attempting any inspection or maintenance.
CAUTION: Never use petrol, thinner, alcohol or similar substances.
Discolouration, deformation or cracking of the housing may occur during
their use.
To maintain the SAFETY and RELIABILITY of the product, repairs, and
any other maintenance or adjustments should be carried out by authorised
service centres, always using original spare parts.
If the device is unused for a long period of time, be sure to remove the
battery.
Do not leave the device connected to the cigarette lighter socket
unattended.
Store the device in a dry place and do not expose it to excessively low or
subzero temperatures.
Clean the unit with a damp cloth and mild detergents.
+ -
' and ' '
RATING DATA
Energy+ cordless compressor 58GE113
Supply voltage (Energy+ battery)
Supply voltage (cigarette lighter)
Rated power
Max. operating pressure
Type of work
Protection class
Mass
Year of production
58GE113 stands for both type and machine designation
NOISE AND VIBRATION DATA
Sound pressure level
Sound power level
Information on noise and vibration
The noise emission level of the equipment is described by: the emitted
sound pressure level Lp
measurement uncertainty). The vibrations emitted by the equipment are
described by the vibration acceleration value a
measurement uncertainty).
The sound pressure level Lp
vibration acceleration value a
measured in accordance with IEC 62841-1. The vibration level a
can be used to compare equipment and to make a preliminary
assessment of vibration exposure.
The vibration level quoted is only representative of the basic use of the
unit. If the unit is used for other applications or with other work tools, the
vibration level may change. A higher vibration level will be influenced by
insufficient or too infrequent maintenance of the unit. The reasons given
above may result in increased vibration exposure during the entire working
period.
In order to accurately estimate vibration exposure, it is necessary to
take into account periods when the device is switched off or when it
is switched on but not used for work. When all factors are accurately
estimated, the total vibration exposure may be significantly lower.
In order to protect the user from the effects of vibration, additional safety
measures should be implemented, such as cyclical maintenance of the
machine and working tools, securing an adequate hand temperature and
proper work organisation.
ENVIRONMENTAL PROTECTION
Electrically-powered products should not be disposed of with household
waste, but should be taken to appropriate facilities for disposal. Contact
your product dealer or local authority for information on disposal. Waste
electrical and electronic equipment contains environmentally inert
substances. Equipment that is not recycled poses a potential risk to the
environment and human health.
"Grupa Topex Spółka z ograniczoną odpowiedzialnością" Spółka komandytowa with its
registered office in Warsaw, ul. Pograniczna 2/4 (hereinafter: "Grupa Topex") informs that
all copyrights to the content of this manual (hereinafter: "Manual"), including, among
others. Its text, photographs, diagrams, drawings, as well as its composition, belong
exclusively to Grupa Topex and are subject to legal protection under the Act of 4 February
1994 on Copyright and Related Rights (ie Journal of Laws 2006 No. 90 Poz. 631, as
amended). Copying, processing, publishing, modification for commercial purposes of the
entire Manual and its individual elements, without the consent of Grupa Topex expressed
in writing, is strictly prohibited and may result in civil and criminal liability.
9
Parameter
Lp = 76.2 dB(A) K= 3 dB(A)
A
Lw = 88.2 dB(A) K= 3 dB(A)
A
and the sound power level Lw
A
, the sound power level Lw
A
given in these instructions have been
h
Value
18V DC
12V DC
60 W
11 bar
S2: 10 min
III
1.6 kg
2022
(where K denotes
A
(where K is the
h
and the
A
given
h
