Druckregler/Filtereinheit
LineLazer lV 3400 Linienmarkiergerät
Ref
Part
Description
13
15E748 BRACKET, manifold
62
CONTROL, assy
62a
15E991 COVER, control box
62b
241443 POTENTIOMETER
62c
116167 KNOB, potentiometer
62d
116752 SWITCH, rocker
62e
287486 BOARD, control, 3400
62f
113045 SCREW, sems, mach, phillips, truss
62g
198650 SPACER, shaft
62h
15F540 LABEL, instructions
63*
287285 CAP, manifold(includes 103,105)
67*
15H561 MANIFOLD, filter
87
111801 SCREW, cap, hex hd
98*
15C780 HANDLE
99*
111457 O-RING
EIN-AUS-SCHALTER
311091K
Schaltplan für den
Pressure Control
Druckregler
Wiring Diagram
ZUR ERDE
TO GROUND
KUPPLUNG B
CLUTCH B
ZUM MOTOR
TO ENGINE
STEUERKARTE
CONTROL BOARD
ON/OFF SWITCH
POTENTIOMETER
POTENTIOMETER
Ref
Part
Description
100* 15C972 PIN, grooved
101* 224807 BASE, valve
Qty
102* 239914 VALVE, drain
1
103* 117285 O-RING
104* 244067 FILTER, fluid
1
105* 15C766 TUBE, diffusion
1
106
196177 ADAPTER, nipple
1
141
196181 FITTING, nipple
1
152* 101748 PIPE, plug, sst
1
155* 15F782 HARNESS, transducer, line striper
4
181
196178 NIPPLE, 3/8 x 3/8 in.
1
182
102814 GAUGE, pressure fluid
1
183
241339 KIT, gauge, 3/8 in., includes 181, 182
1
1
* Im Filterreparatursatz 287685 enthalten
4
1
1
ANTRIEBS-
WELLEN-
GEHÄUSE
PINON
HOUSING
KUPPLUNG A
CLUTCH A
ti5542a
TRANSDUCER
SENSOR
Druckregler/Filtereinheit
GETRIEBE-
DRIVE
HOUSING
GEHÄUSE
Qty
1
1
1
1
1
1
2
1
1
1
1
1
1
27
