Electrical protection
Short-circuit protection
Reverse polarity protection
Mechanical stability
One-sided overload
Vibration
Shock
Materials
Pressure port / flange
standard stainless steel 316 / 1.4401
Diaphragm
standard
option
Manufacturing label
Housing
standard option aluminum die cast with epoxy painting (blue)
Filling fluids
standard Silicon oil (-40...125°C)
Explosion protection
Certification
AX18-DGP200
Maximum safety limits for intrinsi-
cally safe version
Certification
AX-18B-DGP200
Max. ambient temperature
Miscellaneous
Display (optionally)
configuration
Mounting bracket (optionally)
Ingress protection
Installation position
Weight
Current consumption
CE-conformity
Connections
Electrical connection
Process connections
Standard
option
permanent
no damage, but also no function
According to the maximum static pressure of differential pressure sensor
5 g RMS (25 ... 2000 Hz)
100 g / 1 ms
stainless steel 316L / 1.4404
®
Hastelloy
C-276
stainless steel 316 / 1.4401
stainless steel 304 / 1.4301
others: on request
IBExU 14 ATEX 1273 X / IECEx IBE 16.0005X
II 1/2G Ex ia IIC T4 Ga/Gb
II 2D Ex ia IIIC T 85 °C Db
Pi = 660 mW, Ui = 28 V, Ii = 93 mA, Ci 29.7 nf, Li negligible
IBExU 15 ATEX 1110 X / IECEx IBE 16.0006X
zone 1: II 2G Ex db IIC T6 Gb
Ex ia: -40 ... 60 °C
Ex d: -40 ... 65 °C
Typee
: LCD
Lines
: 2
Digits
: 8
Bargraph
: 0...100%
Rotatability
: yes, 90°-steps and / or by turn of the electronic case
- offset / span local via 2 buttons
- local configuration with an optional display
- complete configuration via HART
material CF8M or stainless steel 304 / 1.4401
IP 67
any
ca. 3,3 kg
approx. 23 mA
EMV Directive: 2004/108/EC
- terminal clamps in clamping chamber (for cable-Ø max.2.5 mm²)
internal thread 1/4" - 18 NPT / fixing 7/16 UNF
internal thread 1/4" - 18 NPT / fixing M10
oval flange ½" NPT internal thread
adapter M20x1,5
according to DIN EN 60068-2-6
according to DIN EN 60068-2-27
®
EN
others: on request
others: on request
others: on request
others: on request
37
