Quick Guide

1.2 Safety

WARNING
HIGH VOLTAGE
Frequency converters contain high voltage when
connected to AC mains input, DC supply, or load sharing.
Failure to perform installation, start-up, and maintenance
by quali ed personnel can result in death or serious
injury.
Only quali ed personnel must perform instal-
lation, start-up, and maintenance.
Before performing any service or repair work,
use an appropriate voltage measuring device to
make sure that there is no remaining voltage on
the drive.
WARNING
UNINTENDED START
When the frequency converter is connected to AC mains,
the motor may start at any time, causing risk of death,
serious injury, equipment, or property damage. The
motor can start by means of an external switch, a
eldbus command, an input reference signal from the
LCP or LOP, or after a cleared fault condition.
Disconnect the frequency converter from mains
whenever personal safety considerations make
it necessary to avoid unintended motor start.
Press [O /Reset] on the LCP before
programming parameters.
The frequency converter, motor, and any driven
equipment must be in operational readiness
when the frequency converter is connected to
AC mains.
NOTICE
The [O /Reset] key is not a safety switch. It does not
disconnect the frequency converter from mains.
MG02BC4P
Quick Guide•Kurzanleitung•Guide rapide•Guía rápida•Guia Rápido•Краткое
руководство
WARNING
DISCHARGE TIME
The frequency converter contains DC-link capacitors,
which can remain charged even when the frequency
converter is not powered. High voltage can be present
even when the warning LED indicator lights are o .
Failure to wait the speci ed time after power has been
removed before performing service or repair work can
result in death or serious injury.
M1, M2, and M3
M4 and M5
Table 1.1 Discharge Time
Leakage current (>3.5 mA)
Follow national and local codes regarding protective
earthing of equipment with a leakage current >3,5 mA.
Frequency converter technology implies high frequency
switching at high power. This generates a leakage current
in the ground connection. A fault current in the frequency
converter at the output power terminals might contain a
DC component, which can charge the lter capacitors and
cause a transient ground current. The ground leakage
current depends on various system con gurations
including RFI ltering, screened motor cables, and
frequency converter power.
EN/IEC61800-5-1 (Power Drive System Product Standard)
requires special care if the leakage current exceeds 3.5 mA.
Reinforce Grounding in 1 of the following ways:
See EN 60364-5-54 § 543.7 for further information.
Danfoss A/S © 10/2017 All rights reserved.
Stop the motor.
Disconnect AC mains and remote DC-link power
supplies, including battery back-ups, UPS, and
DC-link connections to other frequency
converters.
Disconnect or lock PM motor.
Wait for the capacitors to discharge fully. The
minimum duration of waiting time is speci ed
in Table 1.1.
Before performing any service or repair work,
use an appropriate voltage measuring device to
make sure that the capacitors are fully
discharged.
Size
Minimum waiting time (minutes)
Grounding wire of at least 10 mm
2 separate ground wires both complying with the
dimensioning rules.
1
4
15
2
(8 AWG).
7
1
