Quick Guide
Relay output
Programmable relay output
Relay 01 terminal number
Maximum terminal load (AC-1)
Maximum terminal load (AC-15)
Maximum terminal load (DC-1)
Maximum terminal load (DC-13)
Maximum terminal load (AC-1)
Maximum terminal load (AC-15)
Maximum terminal load (DC-1)
Minimum terminal load on 01–03 (NC), 01–02 (NO)
Environment according to EN 60664-1
1) IEC 60947 part 4 and 5
Control card, 10 V DC output
Terminal number
Output voltage
Maximum load
NOTICE
All inputs, outputs, circuits, DC supplies, and relay contacts are galvanically isolated from the supply voltage (PELV) and
other high-voltage terminals.
Surroundings
Enclosure protection rating
Enclosure kit available
Vibration test
Maximum relative humidity
Aggressive environment (IEC 60721-3-3), coated
Test method according to IEC 60068-2-43 H2S (10 days)
1)
Ambient temperature
Minimum ambient temperature during full-scale operation
Minimum ambient temperature at reduced performance
Temperature during storage/transport
Maximum altitude above sea level without derating
Maximum altitude above sea level with derating
Safety standards
EMC standards, Emission
EMC standards, Immunity
Energy e ciency class
1) Refer to chapter 1.9 Special Conditions for:
•
Derating for high ambient temperature.
•
Derating for high altitude.
2) Determined according to EN 50598-2 at:
•
Rated load.
•
90% rated frequency.
•
Switching frequency factory setting.
•
Switching pattern factory setting.
MG02BC4P
Quick Guide•Kurzanleitung•Guide rapide•Guía rápida•Guia Rápido•Краткое
руководство
1)
on 01–02 (NO) (Resistive load)
1)
on 01–02 (NO) (Inductive load @ cosφ 0.4)
1)
on 01–02 (NO) (Resistive load)
1)
on 01–02 (NO) (Inductive load)
1)
on 01–03 (NC) (Resistive load)
1)
on 01–03 (NC) (Inductive load @ cosφ 0.4)
1)
on 01–03 (NC) (Resistive load)
5%–95 % (IEC 60721-3-3; Class 3K3 (non-condensing) during operation
1)
1)
Danfoss A/S © 10/2017 All rights reserved.
24 V DC 10 mA, 24 V AC 20 mA
Overvoltage category III/pollution degree 2
-25 to +65/70 °C (-13 to + 149/158 °F)
EN 61800-3, EN 61000-6-3/4, EN 55011, IEC 61800-3
EN 61800-3, EN 61000-6-1/2, EN 61000-4-2, EN 61000-4-3,
EN 61000-4-4, EN 61000-4-5, EN 61000-4-6
1
01–03 (break), 01–02 (make)
250 V AC, 2 A
250 V AC, 0.2 A
30 V DC, 2 A
24 V DC, 0.1 A
250 V AC, 2 A
250 V AC, 0.2 A
30 V DC, 2 A
50
10.5 V ±0.5 V
25 mA
IP20
IP21, TYPE 1
1.0 g
class 3C3
Maximum 40 °C (104 °F)
0 °C (32 °F)
-10 °C (14 °F)
1000 m (3280 ft)
3000 m (9842 ft)
EN/IEC 61800-5-1, UL 508C
IE2
29
