6. Optional Accessories

• Air Li er DZ-801
h e air li er is available for manual operation of the measuring rod.
Use it in combination with DK812SALR / DK812SALR5 / DK805SALR / DK805SALR5
/DK812SBLR / DK812SBLR5 / DK805SBLR / DK805SBLR5.
• Mounting Bush DZ-811 is optionally available to mount the measuring unit on Gauge
Stand DZ-501.
• Extension cable
CE22-01: 1 m, CE22-03: 3 m, CE22-05: 5 m, CE22-10: 10 m
55.5
41.5
CK-T12: 1 m, CK-T13: 3 m, CK-T14: 5 m, CK-T15: 10 m
13
4.8
24.3
6.2
35.5
8
(E)
All manuals and user guides at all-guides.com
Cable length: 1, 3, 5, 10 m
Cable length: 1, 3, 5, 10 m
49.5
Bare wire colors
50
Signal
+Vcc
0 V
A
A
B
B
Z
Z
5.5
30.5
14 41.5
Color
Red
White
Blue
Yellow
Orange
Gray
Green
Violet
13.6
5.5
Unit: mm
