4. Specii cations
Output
Resolution
Measuring range
Accuracy (at 20°C)
Measuring force
DK812S
(at 20°C)
Reference point
Maximum
response speed
Air driving
Vibration
resistance
(20 to 2000 Hz)
Impact resistance
(11 ms)
Degree of
*1
protection
Operating
temperature
Storage
temperature
Power supply
voltage
Power
consumption
Cable length
Diameter of stem
*3
Mass
Provided with a carbide ball tip (DZ-123)
Feeler
Accessories
Output cable
length (up to the
electronic section)
Life time
*4
*1
Not including interpolation box and connector
When using the supplied hose elbow and a φ4 mm tube
*2
*3
Not including cable and interpolation box
*4
Depends on the evaluation test dei ned by Magnescale Co., Ltd.
High-resolution models
DK812SAR,
DK812SBR,
DK812SALR,
DK812SBLR,
DK805SAR,
DK805SBR,
DK805SALR
DK805SBLR
A/B/reference point signal
0.1 μm
DK812S: 12 mm, DK805S: 5 mm
1 μm p-p
Downward: 0.6 ±0.3 N
Horizontal: 0.5 ±0.3 N
Upward:
0.4 ±0.3 N
One location (at 1 mm position of spindle movement)
80 m/min
42 m/min
(DK812SALR / DK812SALR5 / DK805SALR / DK805SALR5 /DK812SBLR /
DK812SBLR5 / DK805SBLR / DK805SBLR5)
SAR / SBR : IP66, SALR / SBLR : IP64 (IP67
Mount screw M2.5
Supplied wrench, Instruction Manual, Supplement, +P M4×5 screw (2),
Hose elbow (SAL and SBL types only)
Minimum 30 million cycles without shock
General-purpose resolution
DK812SAR5,
DK812SALR5,
DK805SAR5,
DK805SALR5
dif erential line driver output
(compliant with EIA-422)
DK805S
250 m/min
Vacuum suction
2
100 m/s
1000 m/s
2
0°C to 50°C
–20°C to 60°C
DC +5 V ±5%
1 W
2.5 m
φ8
0
–0.009
Approx. 30 g
Provided with a steel ball tip
Mount screw M2.5
22 m max.
models
DK812SBR5,
DK812SBLR5,
DK805SBR5,
DK805SBLR5
0.5 μm
1.5 μm p-p
Downward: 0.45 ±0.25 N
Horizontal: 0.40 ±0.25 N
Upward:
0.35 ±0.25 N
100 m/min
*2
)
(E)
5
