6.1.2 Thermocouples

Designation
Fe-CuNi "L"
Fe-CuNi "J"
Cu-CuNi "U"
Cu-CuNi "T"
NiCr-Ni "K"
NiCr-CuNi "E"
NiCrSi-NiSi "N"
Pt10Rh-Pt "S"
Pt13Rh-Pt "R"
Pt30Rh-Pt6Rh "B"
W5Re-W26Re "C"
W5Re-W20Re "A1"
W3Re-W25Re "D"
Chromel®-COPEL® "L"
Chromel®-Alumel®
PLII (Platinel)
b The accuracy specifications refer to the maximum measuring range.
Standard
DIN 43710:1985-12
DIN EN 60584-1:2014
DIN 43710:1985-12
DIN EN 60584-1:2014
DIN EN 60584-1:2014
DIN EN 60584-1:2014
DIN EN 60584-1:2014
DIN EN 60584-1:2014
DIN EN 60584-1:2014
DIN EN 60584-1:2014
ASTM E230M-11
GOST R 8.585-2001
ASTM E1751M-09
GOST R 8.585-2001
GOST R 8.585-2001
ASTM E1751M-09
6 Technical data
Measuring range
-200 to +900 °C
-210 to +1200 °C
-200 to +600 °C
-200 to +400 °C
-200 to +1300 °C
-200 to +1000 °C
-200 to +1300 °C
-50 to 1768 °C
-50 to 1820 °C
0 to 2315 °C
0 to 2500 °C
0 to 2315 °C
-200 to +800 °C
-270 to +1372 °C
0 to 1395 °C
b
Measuring accuracy
±0.1 %
±0.1 % from -100 °C
±0.1 % from -100 °C
±0.1 % from -150 °C
±0.1 % from -80 °C
±0.1 % from -80 °C
±0.1 % from -80 °C
±0.15 % from 20 °C
±0.15 % from 50 °C
±0.15 % from 400 °C
±0.15 %
±0.15 %
±0.25 %
±0.1 % from -80 °C
±0.1 % from -80 °C
±0.15 %
25
ITS
68
90
68
90
90
90
90
90
90
90
90
90
90
90
90
