Fronius OPT/i Ethernet iWave190i Installationsanleitung Seite 13

6
6
5
7
Replace the TPC220 PC board
Connect the Ethernet cable to the con-
5
trol panel
Secure the device frame using 3 TX25
6 6
screws
Tightening torque = 3 Nm
Secure Ethernet cable using 2 cable
7
ties
Cut off cable ties
8
7
Place the TPC220 PC board in the PC
1
board holder on the upper holders as
shown
13
