3-9. Fault Code

Fault event
Bus start failure
Bus over
Bus under
Bus unbalance
Inverter soft start failure
High Inverter voltage
Low Inverter voltage
Inverter output short circuited
Negative power fault
Inverter over current
Inverter waveform abnormal

3-10. Warning Indicator

Warning
Battery low
Overload
Battery unconnected
Over charge
EPO enable
Fan failure/Over temperature
Charger failure
I/P fuse broken
Overload 3 times in 30min
Fault code Icon
01 None
02 None
03 None
04 None
11 None
12 None
13 None
14
1A None
60 None
63 None
Icon (flashing)
22
Fault event
Battery SCR short circuited
Inverter relay short circuited
Charger short circuited
Can communication fault
Parallel output current
unbalance
Over temperature
CPU communication failure
Overload
Battery turn-on failure
PFC current failure in battery
mode
Bus voltage changes too fast
Alarm
Beeping every second
Beeping twice every second
Beeping every second
Beeping every second
Beeping every second
Beeping every second
Beeping every second
Beeping every second
Beeping every second
Fault code Icon
21 None
24 None
2a None
31 None
36 None
41 None
42 None
43
6A None
6B None
6C None
