Mounting - ProMinent DULCOFLEX DFXa Schnellstartanleitung

Mounting

Observe the following mounting
instructions:
Access to the dosing head is neces-
sary for changing the tube. Therefore,
ensure sufficient space around the
pump, at least ≥ 80 mm.
NOTICE
To be able to change the tube,
mount the pump free-standing.
Mount Pump
To attach the pump to the ground,
screw the pump to the mounting holes
provided on both sides using a screw
with a diameter < 4.5 mm.
EN 8
≥ 80 mm
2 m*
* available in other versions and lengths
≥ 10 cm
100 – 230 V ±10 %
50/60 Hz
