Step 2 Apply power to the drive
Apply AC power to the drive and observe operator. Three 7-segment display
should show power voltage for 3 to 5 seconds and observe how it runs, factory
sets 5.00. (Frequency Command of 7-segment display should be flashed all the
time.)
Step 3 Check motor rotation without load
• Press the
00.0 to 05.0 Hz.
• Check the operation direction of the motor. If the direction is not correct:
Press the
LED is off, switch T1 and T2.
• Apply power again and press the
direction.
Step 4 Check full speed at 50Hz/60Hz
• Change the frequency with the
key to confirm the setting.
• Set the frequency to 50/60 Hz according to the above regulations.
• Press the
full speed.
• Press the
Emotron AB 01-3991-11r2
key. The 7-segment display will indicate the output frequency
key and turn off the AC power supply. After power indicator
key and inspect the motor operation as motor accelerates to
key and inspect the motor operation as motor decelerates.
key and check the motor operation
or key and please press the
