Technical data

CrashBox Ro-
bacta Drive CMT
PAP
Reset accuracy (1)
Release force
Permitted deflection in x/y direction
Permitted force at maximum deflection in x/y direction
Release force
Permitted deflection in z direction
Weight
Dimensions
a)
b)
12
1
z
b)
in x/y direction
Tolerance
b)
in z direction
Tolerance
At a distance of 300 mm from the robot flange
The force at which the release signal occurs
y
x
y
x
± 0.04 mm a
)
120 N
a
)
±16 N
max. 7°
max. 35 mm a
)
max. 400 N a
)
1200 N
±50 N
max. 4.0 mm
approx. 700 g
Ø90 mm x 122
mm
