Safety Information
Products with the symbol of a crossed out wheelie bin with a
single black line underneath, indicates that parts within the
product must be handled in compliance with the WEEE Di-
rective. The entire product, or the WEEE parts, can be sent to
your "Customer Centre" for handling.

Information regarding Article 33 in REACH

The European Regulation (EU) No. 1907/2006 on Registra-
tion, Evaluation, Authorization and restriction of Chemicals
(REACH) defines among other things requirements related to
communication in the supply chain. The information require-
ment applies also to products containing so called Substances
of Very High Concern (the "Candidate List"). On 27 June
2018 lead metal (CAS nr 7439-92-1) was added to the Candi-
date List.
In accordance with the above this is to inform you that cer-
tain electrical and mechanical components in the product
may contain lead metal. This is in compliance with current
substance restriction legislation and based on legit exemp-
tions in the RoHS Directive (2011/65/EU). Lead metal will
not leak or mutate from the product during normal use and
the concentration of lead metal in the complete product is
well below the applicable threshold limit. Please consider lo-
cal requirements on the disposal of lead at product end of
life.
Regional Requirements
WARNING
This product can expose you to chemicals including
lead, which is known to the State of California to cause
cancer and birth defects or other reproductive harm. For
more information go to
Safety
WARNING Risk of Property Damage or Severe In-
jury
Ensure that you read, understand and follow all instruc-
tions before operating the tool. Failure to follow all the
instructions may result in electric shock, fire, property
damage and/or severe bodily injury.
Read all Safety Information delivered together with
►
the different parts of the system.
Read all Product Instructions for installation, opera-
►
tion and maintenance of the different parts of the
system.
Read all locally legislated safety regulations regard-
►
ing the system and parts thereof.
Save all Safety Information and instructions for fu-
►
ture reference.
Statement of use
This product is designed for installing and removing threaded
fasteners in wood, metal or plastic.
No other use permitted. For professional use only.
4
www.P65Warnings.ca.gov
© Atlas Copco Industrial Technique AB - 9836 2813 00
WARNING Risk of injury
If the torque is higher than 50 Nm, a reaction bar
►
must be used.
The reaction bar is designed for absorbing the reac-
tion torque of assembly power tools.
Product Specific Instructions
Warning / Important
WARNING All locally legislated safety rules regard-
ing installation, operation and maintenance shall be
respected at all times.
• Make sure you are familiar with the operator's instruc-
tions before you use this tool.
• This product is only intended for industrial use and shall
only be operated indoor in dry rooms. This product must
not be used in explosive atmospheres.
• Only use power sockets.
• Do not use gloves.
• When using a suspension yoke, make sure that it is in
good condition and correctly fastened.
• Be prepared of the reaction force which will occur when
the tool is used.
• Make sure that the tool is in good working order and that
the controller is correctly programmed before use to
avoid unexpected behaviour from the tool which may re-
sult in operator injury.
• Be aware of the rotational direction of the spindle before
starting the tool, the reaction force may work in an unex-
pected direction with risk of crush injuries.
• Never put your hand on or close to the reaction bar while
the tool is being used.
• The tool with its drive/controller box is designed to oper-
ate at any setting within its torque range at a primary
voltage of nominal 230V/ 50Hz alternatively 115V/
60Hz, single phase. Refer to the manual for drive unit.
• Always keep the drive unit locked.
• Always make sure that the drive is switched off before
connecting/disconnecting the tool cable.
• Always disconnect the tool from the drive unit before
making any adjustments on or inside the Tool.
• The tool is intended for intermittent use. A typical oper-
ating cycle is 1 s on, 4 s off. This may vary substantially
depending on the application. The acceptable duty cycle
depends on many factors including torque and joint type.
The tool contains protective mechanisms that ensure that
the acceptable duty cycle is not exceeded.
• Avoid using tightening strategies in applications outside
their limitations.
• Major changes in joint characteristics will affect the op-
erator reaction force.
• Consider that a joint failure or a tool error can cause sud-
den unexpected reaction force and possibly injure the op-
erator.
ETP SL21-01-I06-PS
