Option Description
sc100 controller Go to MENU>TEST/MAINT>SCAN SENSORS
sc1000 controller Go to MENU>SYSTEM SETUP>DEVICE MANAGEMENT>SCANNING FOR NEW
DEVICES
Refer to Connect the sensor in a non-hazardous location
3.5 Sensor installation options
The installation and accessory options available for the sensor are supplied with installation
instructions in the hardware kit.
hardware, refer to Replacement parts and accessories
Figure 5 Installation options
1 Rail mount
2 Float mount
3 Air blast system mount (not seawater probe
compatible)
Section 4 Operation
4.1 User navigation
Refer to the controller documentation for keypad description and navigation information.
Push the RIGHT arrow key on the controller multiple times to show more information on the home
screen and to show a graphical display.
Figure 5 shows several installation options. To order installation
4 Chain mount
5 Union mount (not seawater probe compatible)
on page 8 for digital sensor connection.
on page 17.
