Storage conditions
4.2

Fastening the transport lock

AB2400en
■
Before transporting, fasten the transport lock and disconnect the device
from the mains socket.
■
The transport temperature must be between -20 °C and +60 °C.
■
Humidity must not be condensing. Humidity must be between 10% and
80%.
■
Be aware of the weight of the device.
■
When transporting using a transport aid (e.g., a pallet truck), the trans-
port aid must be able to carry at least 1.6 times the transport weight of
the device.
■
Secure the device to prevent it tipping over and falling down during
transport.
■
Never transport the device sideways or upside down.
■
The device must be stored in the original packaging.
■
Only store the device in dry rooms.
■
The storage temperature must be between -20 °C and +60 °C.
■
Humidity must not be condensing. Humidity must be between 10% and
80%.
Personnel:
■
Trained user
6
5
4
Fig. 13: Transport lock
1 Bellows
2 Edge of the centrifuging chamber
3 Right side of device
4 Motor cover
5 Screws and spacer sleeves
6 Foam cylinder
1. Open the lid.
2. For MIKRO 200 R:
Check the bellows (
The edge of the centrifuging chamber (
the bellows.
3. Insert the foam cylinder (
4. Close the lid.
5. Lay the device down onto its right-hand side (
6. Screw in 2 screws with 2 spacer sleeves (
Rev.: 12 / 11.2023
Transport and storage
3
1 ) under the motor cover ( 4 ) for correct seating:
2 ) must be in the groove of
6 ).
5 ).
1
2
3 ).
17 / 39
