3.4 Mounting the accessories
￭￭￭￭￭￭￭￭
14
Mounting the equipment for aspirating solvent
Mount the solvent bottle as follows:
1 Fill the 6.1609.010 adsorber tube and the 6.2811.000 molecular
sieve with cotton.
2 Use the other half of the 6.1801.120 PVC tubing previously cut in
two pieces for aspirating the solvent. Fasten the one end of the tub-
ing to the lower end of the adsorber tube, the other end to the con-
nection nipple for aspirating the solvent.
3 Equip the 6.1602.105 bottle attachment with the 6.1446.040
threaded stopper and the 6.1609.010 adsorber tube.
4 Secure the adsorber tube with the 6.2023.020 SGJ clip.
5 Insert the 6.1819.030 cannula into the last open hole (with medium-
sized diameter) of the 6.1602.105 bottle attachment.
6 Screw the 6.1602.105 bottle attachment onto the solvent bottle.
Instead of the 6.1608.023 amber glass bottle, other reagent bottles
with GL45 thread can be used (e.g. RIEDEL DE HAEN (1 liter), BAKER).
For other bottles another bottle attachment or an additional thread
adapter have to be used.
MERCK bottles: 6.1602.110 bottle attachment
FLUKA bottles, RIEDEL DE HAEN (500 ml): 6.1602.100 bottle attach-
ment with 6.1618.000 thread adapter.
7 Screw the 6.1543.110 transfer tip to the free end of the 6.1805.200
PTFE tubing, insert into the titration vessel and fasten to the titration
vessel lid.
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
