803 Ti Stand
Mounting the equipment for aspirating
Mount the waste bottle as follows:
1 Equip the 6.1602.105 bottle attachment with the 6.1446.040
threaded stopper, the 6.1808.050 tubing adapter and the
6.1446.090 stopper.
2 Plug the 6.1623.000 overflow protection from below into the
6.1602.105 bottle attachment (the opening, the 6.1808.050 tubing
adapter is plugged in).
3 Screw the 6.1602.105 bottle attachment onto the 6.1608.030 waste
bottle.
4 Cut the 6.1801.120 PVC tubing into two halves and use one to aspi-
rate.
5 Fasten the one end of the aspiration tubing to the tubing adapter,
the other to the connection nipple for the waste on the rear of the
titration stand.
6 Insert the 6.1819.050 cannula through the 6.1446.090 stopper into
the waste bottle.
7 Screw the 6.1805.200 PTFE tubing into the 6.1446.090 stopper.
8 Screw the 6.1543.120 aspiration tip to the other end of the PTFE
tubing.
9 Insert the aspiration tip down to the bottom of the titration vessel to
be emptied and fasten it to the titration vessel lid.
NOTICE
The waste bottle should periodically be emptied.
22 Molecular sieve 6.2811.000
3 Installation
￭￭￭￭￭￭￭￭
