where:
X
P
Figure 20
where:
Turbo-V 300HT PCB Controller User Manual / 87-900-884-01 (F)
P = is the DC power drawn by the pump (range 0 to 999 Watt)
KRPM = is the theoretical rotational speed of the pump as a
function of the controller output frequency (range 3 to 56 KRPM)
°C = is the temperature of the outer ring of the upper bearing
(range 00 to 99 °C)
Y = during operation a selected set point condition (1 or 2
contrast inverted) appears when the programmed threshold
speed value is not reached.
Press the CYCLE NUMBER twice and the display shows:
X X X C Y
U M P L
CYCLE = are the cycles performed (range 0 to 9999)
m = is the elapsed time related to the cycle number displayed
(range 0 to 99999 minutes)
PUMP LIFE = is the total operation time of the pump (range 0 to
99999 hours).
Technical Information
C L E X
I F E X
17
Use
X X X X m
X X X X h
