8 (7) 0 High-frequency motor control (approx. 23 kHz)
1 Low-frequency motor control (approx. 19 Hz)
Bit Braking configuration
51
1 (0) 1 Constant braking distance with ABC activated
2 (1) 1 ABC activated
3 (2) 1 ABC direction-dependency deactivated
4 (3) 1 Activate push-pull operation without intermediate stop
5 (4)
1 Activate push-pull operation with intermediate stop
6 (5) 1 Stopping with DC independent of the polarity (only if Bit 3 is
deleted in CV29).
7 (6) Not used
8 (7) 1 Constant braking distance with speed step 0 activated
0-255 Braking distance with activated constant braking distance
52
53 0-255 Slow approach with ABC
54 0-255 Stopping time in push-pull operation, 1 to 256 sec
0-255
55 Sets brightness at function outputs A 255=max
0-255 Sets brightness at function outputs B 255=max
56
57 Function mapping:
Each bit of the CV stands for a function of the digital system:
-
Bit 1(0) for function 1, Bit 2(1) for function 2 and so on up to
59,
Bit 8(7) for function 8. If you wish to allocate a function to the
61
dimming, the respective bit must be set.
0-255 Mapping of Dimming for F-Outputs A to D (no ex-works setting)
57
0-255 Shunting speed (ex-works setting F3)
58
