Lenz Digital plus STANDARD+ V2 Betriebsanleitung Seite 39

support the 28 running-notches mode.
1 Operation with 28 or 128 running notches.
This setting is chosen for digital systems which support the
28/128 running-notches mode.
3 (2) Operational mode:
0 Locomotive only runs in digital operation.
1 Locomotive runs both in digital and conventional operation,
flying splice possible.
4 (3) 0 RailCom transmission disabled
1 RailCom transmission enabled
5 (4) 0 factory pre-set speed curve is used
1 User defined speed curve is used
6 (5) 0 Decoder uses basic address (from CV1)
1 Decoder uses extended address (from CV17 and CV18)
7-8(6-7) Not used
Bit
30 Fault display
1 (0) 1 Light short-circuit
2 (1) 1 Overheating
3 (2)
1 Motor-/Track short-circuit
Range of Function mapping for function outputs:
CV
values In order to allocate a function of the digital system to a function
33
output, look for the section where the row of the desired function
–
meets the column of the desired function output. Enter the
47
number found in the respective CV. For the purpose of
clarification, ex-works settings are shown in bold print.
39
E
1
0
0
0
0
0 (dec)
0
0
0
Ex-works
setting
