Lenz Digital plus STANDARD+ V2 Betriebsanleitung Seite 38

38
address) is deleted in CV29.
2 0-255 Minimum starting voltage
0-255 Starting delay
3
0-255
4 Braking delay
5 0-255 Maximum speed
0-255 Mid speed Vmid
6
-
7 Version number
8 - Manufacturer's ID
0-63 Repeat rate
9
192-231
17 Extended locomotive address, high-order byte
18 0-255 Extended locomotive address, low-order byte
1-99 Multiple traction address
19
28 Bit RailCom configuration
1 (0)
1
2 (1) 1
Bit
29 Settings 1
1 (0) Direction of travel
0
1
2 (1) Running-notches mode:
0
channel 1 release for address broadcast
channel 2 release for data and command acknowledge
normal: locomotive drives forward if the arrow on the manual
control points up.
interchanged: locomotive drives forward if the arrow on the
manual control points down.
Operation with 14 or 27 running notches.
This setting is chosen for digital systems which do not
Information STANDARD+ V2 Decoder
1
6
5
254
48
77
99
77
192
100
0
3(dec)
1
1
6 (dec)
0
1
