2.2

Design of the sensor

Fig. 1: Design of the sensor
1. O-ring
2. Counter and reference electrodes
3. Working electrode
4. Protective membrane cap
5. Membrane cap
6. Tubular seal
12.
11.
10.
9.
8.
7.
6.
5.
4.
7.
8.
9.
10.
11.
12.
Brief functional description
1.
2.
3.
O-ring
Electrode shaft
Clamping disc
2-wire connection
Top section
Opening for M12 cable connector
