1. Description

The EX-6124-2 is a multi-protocol RS-232/422/485 serial Device Server designed to connect RS-
232/422/485 serial devices, including point-of-sale systems, barcode readers, sensors, meters,
weighing systems, CNC controllers and PLCs, to an IP-based Ethernet network. The serial devices
are connected via Ethernet and are available for sharing on the subnet and Internet. Remote
configuration is done via extensive network protocols such as TCP server, TCP client, UDP,
VCOM, serial Telnet, RFC2217, remote pair master slave or Modbus RTU. To ensure backward
compatibility with legacy serial devices running existing COM port application software, the EX-
6124-2 provides a virtual COM port (VCOM) that perfectly migrates your serial application without
modifying the software. In addition, serial devices can communicate with each other in peer-to-
peer mode without the need for an intermediate PC or conversion software.
Features:
•
4x RS-232/422/485 DB9 serial port over RJ45 Ethernet 10/100Mbps
•
Serial Modes: RS-232, RS-422, RS-485 2-wire & 4-wire
•
Network Protocols: TCP Server, TCP Client, UDP, VCOM, Serial Telnet, RFC2217,
•
Configuration: Windows-based SDS Administrator Utility and Web-Browser
•
15KV ESD-Protection for all serial Signals
•
Supports 5V over serial Connector
•
Certificates

2. Extent of delivery

Before you integrate the EX-6124-2 into your network, you should first check the contents of the
delivery:
•
EX-6124-2
•
Power Supply (12V/3A)
•
Manual
© Copyright 2023 by EXSYS Vertriebs GmbH. All rights reserved
Remote-Pair-Master-Slave, Modbus Server, Modbus Client und SNMP
