ROTOCLEAR S3

Technical data

Basic data

Dimensions
Field of vision
Connections
Stator
Sealing ring
Rotor
Motor
Rated speed
Rated voltage
Power consumption
Rated current
Current draw
Noise emissions
Overpressure in the connection box
Air consumption
Air purity
Storage temperature
Operating temperature
Interfaces
Electrical supply
Protective hose in the chip chamber
Air supply line
Fastening by screws
on polycarbonate
Connection box alignment
Ø 290 mm (290 mm × 333 mm) × 34 mm
Ø 232 mm (minus Ø 40 mm in the centre)
Internal thread M16 × 1.5, 10 mm
PBT, 8 mm ESG tempered glass
Ø 275 mm × 3.5 mm FPM (Viton)
Alu, PBT, 4 mm ESG, magnetic ring NdFeB
Brushless with blocking and reverse polarity
protection
max. 2300 rpm
24 VDC (16–28 V)
24 W (start-up power consumption < 60 W)
1.0 A, (start-up current < 2.5 A)
0.6–0.7 A (upon delivery)
< 65 dB(A) (standard measurement on operator
side)
2 – 5 mbar (200 – 500 Pa) (required for the
Rotoclear seal guarantee)
1.2 m³/h (at 200 Pa) (with purge air connection)
ISO 8573-1:2010[3:4:3] (required if connected to a
purge air supply)
-20 °C to 60 °C permissible
10 °C to 60 °C permissible
2 x 0.75 mm², Ø 6 mm (sheath), + brown, - blue,
PUR sheathed, suitable for drag chains
Ø 17 mm × 2 mm, 2.0 m, oil-resistant, PUR
sheathed
Ø 8 mm × 1 mm, 8.5 m or optional air inlet
6-16 mm pane thickness, Ø 256 mm hole circle,
10 × 36° × Ø 10 mm
0° to 360°
80
