INSTRUCTION MANUAL

Preparing the parts

Remove the rotor and the stator from the packag-
ing. Both components are packed separately.
When unpacking, pay attention to cleanliness.
Store all parts on a clean, soft surface or in the
original packaging. Handle the product with care.
The unit must be protected from any shocks, as
they may damage the bearing unit, the rotor or
other parts.
There is a magnet in the rotor. Beware of the mag-
((
))
netic forces if you have an active medical implant.
Keep a minimum distance of 20 mm between the
implant and the rotor.
Loosen the cover on the connection box and loos-
en the screws of the strain relief.
Remove the M16 screw plug. Put all parts back in
the packaging or onto a clean and non-metallic
surface.
The Rotoclear S3 can also be mounted with the
machinery glass installed. The alignment of the
connection box can be freely selected between
0-360°. Alignments of 0, 90, 180 or 270° are rec-
ommended.
The unit is mounted on the inner side of the ma-
chinery glass that is exposed to media.
Make sure that the tightening torques are ob-
served! Exceeding the torque values can destroy
parts of the Rotoclear S3. If the tightening torque
falls below this value, the sealing ring may not pro-
vide the desired sealing effect.

Required tools

Allen key, WAF 6 mm
Screwdriver 12 × 1 mm and 3 × 0.5 mm
Screwdriver Tx 10
Side cutter
Stripping tool
Stripping pliers for 0.75 mm²
Wire end ferrules for 0.75 mm²
Crimping pliers for wire end ferrules
Open-ended spanner; WAF 22, 23, 25
Cleaning cloths
Isopropyl alcohol
53
