Safety and operating instructions
The tightening torque is adjusted by altering the tension of the clutch spring by means of the adjustment
disc and the key provided. Place the key in the hole in the front part. The adjustment key is to be turned
clock-wise to increase the tightening torque. Always finish the adjustment at a "holding position" (located
each 1,5 turns of the key). If the torque setted is too high, there will be no click-sound from the clutch and
the green LED will not lighten, but the motor will be shut off.
To prevent the screw joint from being damaged, it is recommended to start at low torque setting.
Don't adjust the torque over the maximum recommendation as it will result in improper function and
faster wear.
Battery chargers
Use only Atlas Copco battery charger (see optional accessories). Please see separate instructions deliv-
ered with the charger.
Battery Packs
Fully charge new or long time unused battery packs before using your battery machine. Full loading ca-
pacity of battery pack is reached after 4 – 5 chargings.
The contact points of chargers and battery packs must be kept clean.
If the machine will not be used for 100 hours or longer: separate the battery from the machine. Otherwise
the electronics will discharge the battery.
Battery Pack Reception
Put the battery pack in the battery machine so that the clamps are secured. The battery can be placed in
two alternative positions, pointing forward or backward, for best accessibility and balance. Removal of Bat-
tery Pack: Press down the button, then take out the battery pack of the battery machine.
Since a battery discharge itself slowly, it should remain in the charging unit which provides a trickle
charge.
Signal lights
The green LED indicates an OK tightening, i. e. the machine has been shut off by the clutch. When the
battery energy is not sufficient for any more correct tightening, the motor will be shut off and the yellow
LED will light up.
Screwdriver direction
Direction
Clockwise
Anti-Clockwise
Standby behaviour
Valid to Serial No. A3482444
To save battery power the tool will automatically switch to a standby mode when inactive. All LEDs will be
off in standby mode.
Press the trigger to wake up the tool and leave standby mode. The first time the trigger is pressed the
tool will run directly in clockwise direction, even if the operating switch is set to counterclockwise!
The second time the trigger is pressed, the tool is awake and will run in the direction set by the operating
switch.
Standby behaviour
Valid from Serial No. A3482445
6
EN
© Atlas Copco Industrial Technique AB - 9836 9627 00
LEDs
Off
Flashing rotatory red & green
BCP BL2-I06
