Service instructions
Test joints - Hard joints
Ref. No.
3
3
3
3
3
Test joints - Soft joints
Ref. No.
3
3
3
3
3
20
EN
Ordering No.
4145 0958 80
4145 0958 81
4145 0958 82
4145 0958 83
4145 0958 84
Ordering No.
4145 0959 80
4145 0959 81
4145 0959 82
4145 0959 83
4145 0959 84
© Atlas Copco Industrial Technique AB - 9836 9627 00
Torque rate Nm / rev.
10
25
45
80
130
Torque rate Nm / rev.
0.7
1.5
3.0
5.5
10.0
BCP BL2-I06
Torque range Nm
0.5 – 0.5
1.5 – 3.0
3.0 – 6.0
6.0 – 9.0
9.0 – 25.0
Torque range Nm
0.6 – 2.0
1.5 – 4.0
3.0 – 7.0
5.5 – 10.0
10.0 – 25.0
