BCP BL2-I06 EN Safety and operating instructions

General information

EC DECLARATION OF CONFORMITY

We, Atlas Copco Industrial Technique AB, S-105 23 STOCKHOLM, SWEDEN declare that the product
(with name, type and serial number, see front page) is in conformity with the following Directive(s):
2006/42/EC, 2014/30/EU,2011/65/EU
Harmonised standards applied:
EN 55014:2017, EN 55014-2:2015, EN 62841-1:2015, EN 62841-2-2:2014 + AC:2015 EN
61000-6-2:2005, EN 61000-6-3:2007 + A1:2011
Technical file available from:
Quality Manager, Atlas Copco Industrial Technique, Stockholm, Sweden
Stockholm, 1 July 2013
Tobias Hahn, Managing Director
Signature of issuer
RoHS and WEEE
Information concerning Restriction of Hazardous Substances (RoHS):
This product and its information, meets the requirements of the RoHS Directive (2011/65/EU).
Information concerning Waste of Electrical and Electronic Equipment (WEEE):
This product and its information, meets the requirements of the WEEE Directive (2012/19/EU), and must
be handled according to the directive.
The product and/or its battery are marked with a crossed trashcan, see figure below.
The symbol indicates that parts within the product must be handled in accordance with the WEEE Direc-
tive. These parts are indicated as "WEEE" in the Spare part list, see under Remarks.
The entire product, or the WEEE parts, can be sent to your "Customer Centre" for handling.
For more information, consult the website
http://www.atlascopco.com/.
Choose Products - Links and downloads, and click EU RoHS and WEEE directives (ENGLISH only).
Handling
Operating
With the operating switch in the forward position, the screwdriver is started by pressing the trigger. Run
the screwdriver till the preset torque is reached and the clutch releases. Then you will hear a click sound
from the clutch and the green LED will lighten and the motor will be shut off.
Operating switch
The trigger must be released before changing the operating switch.
Temperature
Temperature in excess of 50°C reduce the performance of the battery. Avoid extended exposure to heat
or sunshine (risk of overheating).
Setting of tightening torque
For accurate operation and safety, the tightening torque of the screwdriver must be set correctly in relation
to the screw joint. Check the torque figure for the actual joint and the tightening torque given to the joint.
Atlas Copco's Torque Analyser, ACTA 4000, plus an appropriately-sized in-line rotary transducer, such as
IRTT, are suitable instruments for checking the torque, (see fig. and our main catalogue).
© Atlas Copco Industrial Technique AB - 9836 9627 00 5
