Outdoor sensor/channel setting

You can use the weather station with up to 3 outdoor sensors at the same time.
Open the battery compartment of the outdoor sensor 40 and select a channel (1-3)
by using the Channel selection switch 39. Press and hold the CHANNEL-button 16
for 3 seconds or until an audible signal sounds. The weather station will now attempt
to receive the signal 3.
Now press the TX-button 37 to manually transmit the temperature from the outdoor
sensor to the weather station.
Close the battery compartment. Press the °C/°F-button 36 to select °C-Celsius or
°F-Fahrenheit.
! Note: The outdoor sensor must be within a maximum distance of
100 m of the weather station with no obstructions.
If you are using mutliple outdoor sensors: Press the CHANNEL-button 16 to select
the reception channel.
The rotation symbol 30 on the display at indicates that the weather station is
rotating through channels 1-3.
Only active outdoor sensors are displayed. Press and hold the CHANNEL-button
16 to remove unused channels.
If you add another outdoor sensor, reset the device. The wireless weather station will
automatically detect the outdoor sensor, or you can press the TX button 37 on the
outdoor sensor to transmit the signal manually.

Outdoor temperature tendency

The outside temperature 2 and the temperature trend 29 is displayed upon
successful reception from the outdoor sensor.
Outdoor temperature rising
Outdoor temperature constant
Outdoor temperature falling

Indoor humidity

The current indoor humidity 11 is shown on the display. The comfort icon
10 can show 3 levels of comfort:
< 40 %
DRY
< 20 °C
20 – 26°C
> 26 °C

Maximum and minimum values

The maximum and minimum temperature and humidity are stored as soon as the
batteries are inserted.
Briefly press the - MAX/MIN-button 19 to display the maximum MAX, minimum
MIN and current indoor temperature 9, outdoor temperature 2 and humidity 11 on
the display. To delete the maximum and minimum values, press and hold the
- MAX/MIN-button 19 for 3 seconds. An audible signal will sound and the stored
values will be deleted. The weather station will immediately restart recording of the
values.

Battery level indicator

If the batteries run too low to power the weather station, the outdoor sensor and
signal transmission, the battery level indicator 1 or 8 will appear on
the display. Replace the batteries in all devices as soon as possible.
Restart the weather station.
40 – 60 % > 60 %
COMFORT HUMID
/
/
- 23 -
