10. MULTI I/O
The multi I/O feature allows flexible classification of digital inputs and
outputs for internal device features or status updates.
This allows the adjustment of Thyro-AX for very specific customer and
application related requirements.
In table 9 are listed the features which can be assigned to the multi I/O
inputs and outputs.
FUNCTION OUTPUT
OFF
Events
SYT-OUT
SYT-Time
SYNC_OUT
REL_OUT
THY_POS
THY_NEG
TS_TIME
T0_TIME
OUTPUT
BUS
REMARKT
No function.
Output of messages (events).
Messages can be set.
Mains load optimization, Output signal for
following unit.
Mains load optimization, Signal at the end of
waiting period.
Determined square wave signal of SYNC
voltage to which the unit synchronizes
50Hz / 60 Hz.
Position of relay.
Logic signal for pos. thyristor.
Logic signal for neg. thyristor.
Logic signal for turn-on time Ts at TAKT.
Logic signal for cycle period T .
0
Signal for level of modulation
by flashing frequency.
Signal when the bus module is active.
FUNCTION INPUT REMARK
off No function.
SYT-IN Mains load optimization, Input signal of
previous unit.
SWITCH Input of operating mode SWITCH.
BUS_SW Input for selection of setpoint
(Local / Remote).
OPERATE Input for switching operating mode between
VAR and TAKT. Prior VAR must be active as
operating mode.
Dig_SW2_UP Increase digital setpoint 2 with external
button.
Dig_SW2_DOWN Decrease setpoint 2 with external button.
TAB. 11 MULTI I/O
In table 12 of chapter Technical Data are listed the technical specifica-
tions of the five different multi I/O inputs and outputs. Please note that
they are distinguished from each other, e.g. in signal level, in inverting,
in capacity, etc.
Thyro-Tool AX is necessary for changing the default setting of multi I/O
assignment.
